Malo 36

Full Sales Inventory

CONSTRUCTION

RCD Status:

•    The yacht conforms with the essential safety requirements of Directive 94/25EC (Recreational Craft Directive) and is categorised A – “Ocean”

Hull Construction:

•    GRP moulded hull of sandwich construction.

•    Hull laminate of a combination of Isophthalic and Orthophthalic polyester laminate.

•    Hull cored with balsa, providing insulation to hull construction.

•    Longitudinal and transverse bulkheads are laminated directly onto the hull.

•    Laminate grid of Internal ribs and stringers individually laminated to hull internally.

•    Galvanised steel mast support.

•    Hull finished externally with NGA gel coat for maximum protection against water penetration.

•    Blue sheer band and boot top stripes in original gelcoat finish.

•    Moulded rubbing strake in hull with protective aluminium capping.

•    Below the waterline finished with blue antifouling

Deck & Superstructure Construction:

•    GRP moulded deck and coach roof of sandwich construction.

•    Balsa core with polyester laminate.

•    Aluminium reinforcing in way of deck fittings.

•    Hull to deck joint secured with mechanical fastenings, over laminated.

•    Laid teak decking on side decks, coachroof and in cockpit. 12mm solid teak.

•    The “targa” arch is of moulded GRP construction with stainless steel studs built in securing it to the deck.

•    The deck has four scuppers draining on the waterline to prevent dirt markings on the hull.

•    Fixed windscreen forward of companionway with alloy frame with screens of safety glass.

Keel & Rudder:

•    External lead ballast keel of the long fin shape.

•    Keel secured with stainless steel bolts.

•    GRP moulded, semi-balanced rudder.

•    Partial depth skeg hung.

MACHINERY

Engine & gearbox:

•    Yanmar 3JH-4E 3-cylinder, naturally aspirated, indirectly cooled diesel engine producing 39hp @2,900RPM

•    Fresh water engine cooling via raw water intake and heat exchanger

•    Kansaki reversing marine gearbox

•    Racor turbine fuel filter

•    Single lever morse control

Maintenance & Performance:

•    Engine last serviced spring 2025

•    Engine hours estimated at approx 1,000hrs

•    Cruising speed under engine 6kts

Propulsion & Steering:

•    Aquadrive thrust bearing coupling assembly (2022)

•    Cutlass bearing replaced 2022

•    Stainless steel propshaft

•    Dripless type shaft seal

•    Cable-driven wheel steering

•    Stainless steel wheel with leather cover

•    Emergency tiller

Autopilot:

•    Raymarine ST6001+ control head

•    Raymarine SmartPilot series course computer

•    Raymarine linear drive, direct to quadrant

ELECTRICAL SYSTEMS

Voltage systems:

•    12vDC onboard power system

•    220vAC shorepower/inverter supply

Battery Banks:

•    Domestic/Anchor Battery Bank – 3x 12vDC, 115Ah lead acid batteries (2024)

•    Engine Battery – 1x 12vDC, 70Ah, Lead acid battery (2024)

Charging:

•    Sterling Power ProCharge-Ultra battery charger (2016)

•    230vAC – 12vDC, 30amp

Alternator:

•    Single-engine driven alternator, 12vDC, 80amp

•    Septor 1275 charger splitter

Battery Monitor:

•    Battman amp-hour meter display at switch panel

•    Voltmeter at switch panel

Inverter:

•    12vDC – 230vAC inverter

Shore Power:

•    Extension lead to connect to shore supply

•    Single 16 amp connection point

•    Hardwired RCD-protected system.

•    3 pin UK sockets, battery charger, immersion heater

Other Electrical:

•    12vDC auxiliary charging socket at chart table

PLUMBING & GAS SYSTEMS

Fresh Water:

•    Pressurised hot and cold water systems

•    Mixer tap in galley

•    Manual hand pumped fresh water tap in galley

•    Mixer tap in heads, head extending out for use as shower head

•    Hot water provided from calorifier, heated by engine cooling water or 230VAC immersion heater

Bilge Pumps:

•    Manual Bilge Pump

•    Electric Bilge Pump

Gas System:

•    Gauges for each water tank at switch panel

•    Gauge for fuel tank at switch panel

TANKAGE

Fuel:

•    Single fuel tank

•    Stainless steel tank construction

•    Approximate capacity 235ltrs

Fresh Water:

•    Twin fresh water tanks

•    Stainless steel tank construction

•    Approximate tank capacities 190ltrs and 210ltrs

•    Approximate total capacity 400ltrs

Black Water:

•    Single black water tank

•    Alloy tank construction

•    Approximate capacity 70ltrs

•    Discharging by gravity overboard or via deck suction

Tank Monitoring:

•    Gauges for each water tank at switch panel

•    Gauge for fuel tank at switch panel

NAVIGATION & COMMUNICATION EQUIPMENT

On Deck:

•    Plotter/Radar – Raymarine Axiom +12RV display with Raymarine Quantum radar scanner mounted on mast  (2022)

•    Depth – Raymarine ST60

•    Speed/Log – Raymarine ST60

•    Wind – Raymarine ST60

•    Repeater – Raymarine Graphic display

•    Magnetic Compass – Plastimo Olympic 135

Below Decks:

•    Repeater – Raymarine Graphic display

Communications Equipment:

•    VHF – Simard RD68 vhf with repeater speaker in cockpit

•    Navtex – McMurdo ICS NAV 6 – not operational

DOMESTIC EQUIPMENT

Galley:

•    Cooker – Smev gas cooker, 2 burner, grill and oven, gimbal mounted

•    Fridge – Built-in, top-loading fridge with ice box, 12vDC water cooled compressor

•    Double stainless steel sink

•    Mixer tap

•    Manual hand pump freshwater tap

Heads:

•    Toilet – RM Manual marine toilet

•    SeaSmart Sanitiser fitted to incoming water line for toilet

•    Wash hand basin

•    Mixer tap extending out for use as shower head

•    Teak grating with shower sump beneath

•    Heads seacock and holding tank diverter valave replaced in 2023

Heating:

•    Eberspacher D4 diesel fired, blown air heating system

•    Thermostatic cabin controller

•    Outlets in forward cabin, saloon, aft cabin and heads

Lighting:

•    Overhead lighting throughout interior

•    Bulkhead-mounted reading lights in saloon and cabins

•    Chart table red/white working light

•    Cockpit lighting mounted in targa arch

•    Engine space lighting

Entertainment:

•    Alpine Radio/CD/USB head unit

•    Speakers in saloon

ACCOMMODATION



Summary of Accommodation:

•    Double master cabin forward

•    Saloon providing two occasional single berths

•    Nav Station

•    Galley

•    Heads

•    Double aft cabin

Accommodation Finish:

•    Joinery work below decks of mahogany veneered panels with solid mahogany trims.

•    Wood work finished in a hand-polished matte varnish.

•    Sole boards throughout of teak and koto veneered plywood finished in a hard varnish.

•    Mid-Blue fabric upholstery throughout

•    Fitted blackout blind/insect screens for deck hatches in saloon and forward cabin

•    Curtains for all portlights

•    Laminate worktop in galley

•    Laminate countertop in heads

•    Teak sole grating in heads

Description of Accommodation from Forward:

Forward Cabin:

•    Double V-berth forward

•    Storage lockers above bunk, outboard forward, port and starboard

•    Standing room aft of bunk.

•    Short bench seat with hanging locker outboard to port side of standing space

•    Storage locker unit to starboard with small countertop above

•    Two storage drawers beneath aft end of bunk

Main Saloon:

•    Fixed, extendable saloon table offset to port with single drop leaf on starboard side

•    Wrap around U-shaped settee to port

•    Bench settee to starboard.

•    Settees converting to occasional use single berths, settee back rests lifting out to extend bunk width if required

•    Locker doors on bunk front base to starboard allowing access to storage beneath without removing cushions

•    Counter tops outboard of settee backs port and starboard with book shelf area centrally and storage lockers forward and aft

•    Bulkhead-mounted clock and barometer

Navigation Station:

•    Located to starboard, aft of saloon.

•    Forward-facing chart table with a dedicated navigator's seat.

•    Chart storage within table top with three drawers beneath table forward.

•    Ships switch panel, DSC VHF, repeater etc mounted outboard of table

•    Storage locker beneath navigators seat and deep book locker outboard of seat

Galley:

•    L-shaped galley to port of companionway

•    Inset double stainless steel sinks in worktop forward, inboard

•    Chopping board infill sections for both sinks

•    In-built top-loading fridge beneath worktop outboard forward

•    Gimbal-mounted gas cooker outboard with worktop infill section to fit over

•    Overhead lockers outboard with internal shelfs

•    Range of lockers and drawers beneath worktop with pull-out chopping board aft of cooker

Heads:

•    Located to starboard side of companionway, accessed aft of nav station

•    Forward-facing marine toilet located inboard aft.

•    Countertop running outboard forward with inset wash hand basin, storage lockers beneath countertop

•    Vanity locker outboard of countertop

Aft Cabin:

•    Located to port and accessed through the galley area

•    Standing room at forward end of cabin with hanging locker outboard

•    Double berth aft extending inboard beneath cockpit sole

•    Storage lockers above bunk, outboard aft

•    Access under bunk to sterngear, calorifier and battery box

DECK EQUIPMENT



Rig:

•    Deck stepped, double spreader, masthead, sloop rig (2017)

•    Sliver anodised alloy mast and spars

•    Stainless steel standing rigging (2004)

•    Chromed bronze rigging screws

•    Harken MkIII roller reefing system on forestay

•    In-mast roller reefing mainsail

•    Selden rod kicker

•    Mainsheet mounted on top of targa arch

•    Lewmar Dominon rope clutches for lines lead aft on port side

Winches:

•    Primary Winches – 2x Andersen 46, two-speed, self-tailing

•    Secondary Winches – 2x Andersen 12, single-speed, self-tailing

Sails:

•    Mainsail – White dacron, in-mast roller reefing.

•    Genoa – White dacron, blue UV Strip, roller reefing

General:

•    Stainless steel pulpit rail

•    Deck-mounted stainless steel stanchions supporting double tier guardwires

•    Guardwire gate sections aft to port and starboard

•    Split stainless steel pushpit rail with gate section centrally

•    Outboard storage bracket to port side of pushpit

•    Toerail-mounted alloy mooring cleats forward, midships and aft

•    Below deck anchor locker forward with anchor locker mounted within locker space

•    Dorade ventilator mounted immediately forward of mast with stainless steel guard rail

•    Hardwood grabrails running length of coachroof from mast aft to windscreen

•    Lines lead aft to cockpit along port side of coahroof

•    Alloy-framed fixed windscreed with blue canvas sprayhood above

•    GRP Targa arch with mainsheet track mounted on top

•    Rope clutches for lines lead aft mounted outboard of targa arch on port side

•    Primary and secondary winches mounted on cockpit coamings to port and starboard

•    Bench seating to port and starboard sides of cockpit, forward of pedestal

•    Cockpit locker beneath starboard seating

•    Emergency escape hatch for aft cabin beneath port seating

•    Teak, double drop leaf folding table, with teak extension section for forward end, mounted on forward face of pedestal

•    Engine control panel mounted within recessed area to starboard side of cockpit coaming

•    Autopilot control and VHF speaker mounted within recessed area to port side of cockpit coaming

•    Bench seat spanning cockpit cockpit aft with access to large cockpit locker beneath

•    Short section of deck aft of cockpit with lazarette locker below

•    Stainless steel folding swimming ladder, can be deploy to port or starboard sides as well as transom

Anchoring & Mooring:

•    Anchor self-stowing in stem roller

•    Single bow roller

•    Bower Anchor – 15kg, stainless steel Bruce anchor on chain rode

•    Anchor Windlass – Lofrans Airon electric windlass with plug-in remote control

•    Mooring Warps – Selection

•    Fenders - Selection

Canvas Work:

•    Sprayhood (2022)

•    Cockpit Tent – Roll up side and aft panels (2022)

•    Wheel cover

•    Cockpit Winter Cover (2022)

Tender:

•    Inflatable dinghy – Avon Redcrest, seat, stainless steel outboard bracket and oars

SAFETY EQUIPMENT:

General note on safety equipment: Any safety equipment such as liferafts, Epirbs, fire extinguishers and flares etc. are usually personal to the current owner(s) and if being left on-board as part of the sale of a used vessel may require routine servicing, replacement, or changing to meet a new owners specific needs.

Navigation Lights:

•    Masthead anchor light

•    Masthead tri-colour light

•    Steaming light

•    Deck flood light

•    Low level running lights.

Life saving:

•    Plastimo rescue buoy and line

Disclaimer

Grabau International Scotland offers the details of all vessels in good faith but cannot guarantee or warrant the accuracy of this information or warranty the condition of any vessel and the details do not constitute a part of any contract. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. All vessels are offered subject to prior sale, price change, or withdrawal without notice. Grabau International Scotland provides professional yacht conveyancing and legal transfer of title for all yachts as per the ABYA Code of Practice with all deposit payments and final balance payments processed through secure dedicated client accounts solely for that purpose. Our dedicated client accounts are written in trust at Natwest Bank and we are fully insured.
