Dufour 405 Grand Large

Sail Area

I : 47.58 ft

J : 14.75 ft

P : 44.25 ft

E : 15.08 ft

Working Sail Area : 861.00 sq ft

Additional Description

• Both cockpit seats port and starboard and the helmsman seat covered in FSC Iroko.
• 2 large side lockers with lids fitted with padlock hasps.
• GRP steering pedestals.
• Rudder stock head under helmsman?s sole for installing the emergency tiller.
• Engine lever and control panel easily to hand for the helmsman on the starboard side.
• Transom open in centre with a tipping helmsman?s seat giving access to the swim/boarding platform.
• Gas cylinder locker starboard aft.
• Life raft stowage in dedicated locker in front of helmsman seat.
• Cockpit shower in port aft locker.
• Telescopic stainless steel bathing ladder.

Additional Description

• All joinery work is finished in prime choice Moabi mahogany, with fiddles, mouldings and framings in solid wood.
• Cabin doors have a blocking system in order to keep them open where necessary.
• Floor in solid Moabi wood.
• Saloon cushions and mattress fabrics have removable covers.
• The cabin linings are in stylish white marine plywood.

  > > > COMPANIONWAY > > >

• Sliding companionway hatch and washboard in Plexiglas with stops and lock.
• Curved wooden steps and access to engine by lifting stair case on jacks.
• Two handrails.
• Dedicated stowage for companionway door inside the boat.

  > > > FORWARD CABIN > > >

• Large berth approximately 195 cm long with a 10cm thick mattress with washable cover.
• Under the berth: 160 litre water tank and access to stowage locker.
• Full length shelf with sea-fiddle over the berth alongside the hull. Large hanging locker with shelves.
• Access to navigation instrument transducers.

  > > > AFT CABIN ( S ) > > >

• Double berth approximately 193 cm long. 10 cm thick mattress with washable cover.
• Large hanging locker with double door and shelf above.
• Shelf with sea-fiddle over berth.
• 200 litre fuel tank under starboard berth. 200 litre water tank under port berth.
• Battery switches on the vertical area of the starboard berth.
• Technical area with storage facilities between aft berths.

  > > > FORWARD HEAD > > >

• Spacious head compartment with shower. Manual marine toilet, moulded washbasin, large mirror and chrome plated brass mixer tap with shower unit.
• The shower has direct drainage by an electric pump.
• 45 L Holding available as an option.

  > > > AFT HEAD > > >

• Spacious head compartment with shower.
• Manual marine toilet.
• Bath room with integrated wash basin in synthetic «Corian ®» stone.
• Chrome plated brass mixer tap hot/cold with shower head.
• Large mirror.
• The shower has direct drainage by an electric pump.
• 50 L holding tank as standard.

  > > > SALOON > > >

• A large U-shaped settee is on the port side with cushions made out of foam with washable covers. A central fixed settee has a hinged stowage area underneath.
• Further stowage is available under seats and behind backrests.
• Stowage lockers with doors and bookshelf above the settee.
• Big saloon table with integrated plate holder.
• Stainless steel mast pillar.
• 4 hull port lights to bring light into the interior.

Additional Description

• 12V DC system. Switchboard with circuit breakers, voltmeter, 12V outlet.
• 1 x 100 Ah engine battery. 1 x 100 Ah service battery.
• Switch for each battery.

Additional Description

• L-shaped galley in the 2 cabin version.
• Longitudinal shaped galley in the 3 cabin version.
• Worktops in Corian®, Double stainless steel sink.
• Chrome plated brass mixer tap for pressurised water.
• Two burner cooker with oven and grill on gimbals.
• 12V electric refrigerator unit (180 litres) with both frontal and top opening.
• Cutlery drawer and PVC stowage baskets.
• Upper cabinets, one of which can house a microwave oven.
• Crumb tray under sole.

Additional Description

• Volvo 40 hp (29.1 kW). Sail-drive transmission.
• Heat exchanger, anti-siphon valve. Large capacity sea water strainer.
• Control panel close to helmsman with hour meter, engine stop and tachometer.
• Alternator with battery isolator.
• 200 l fuel tank with gauge on electrical switchboard.
• Fuel filter with water separator.
• Emergency fuel shutoff handle.
• Engine room ventilation blower, and two ventilation hoses.
• Two-blade fixed propeller.
• Access to the engine from front and both sides.
• Independent engine bilge.
• Quality sound proofing using high density foam.

Additional Description

• Hand laminated GRP hull.
• The NPG gelcoat (the first layer of cloth is impregnated with NPG resin) forms an optimum barrier against osmosis.
• Inner moulded hull bottom, structural grid laminated to the hull. Deck in Balsa core sandwich, made by Infusion process.
• Draft 2.03 m, cast iron keel, bolt loads taken up by stainless steel backing plate.
• Semi-elliptical rudder, filled with closed cell epoxyfoam.
• Stainless steel, solid stock.

Additional Description

• Wooden handrails on roof.
• Wooden toe rail.
• Self-draining chain locker with eye bolt and integrated windlass bracket, lid with locking bolt.
• Stem head fitting, double anchor roller.
• Pulpit with wooden step and separate green/red LED navigation lights.
• Pushpits with horseshoe buoy bracket, flag pole holder, navigation light, and opening cable gate with hook.
• Stanchions with two levels of life line.
• Six aluminium mooring cleats. Single stainless steel chain plate for cap shrouds/aft lower shrouds.
• Two chain plates for the backstay.
• Two deck fillers for water and one for fuel.
• Mainsheet track on and adjustable traveller on coach roof. Boom vang.
• Genoa sheet tracks with piston lead blocks. Genoa sheet turning blocks on cockpit coaming.
• 4 and 3 sheave deck organizers for halyard returns, mainsail sheet and reefing lines.
• Stainless steel swan neck electric/electronic cable gland.
• 9 clutches on coach roof.
• Two x 40 ST halyard winches on the roof.
• Two x 46 ST genoa winches on cockpit coamings close to the helmsman.

Sails & Rigging

• Anodised aluminium mast with double swept backed spreaders, deck stepped.
• Anchor, steaming and deck light.
• Boom topping lift cleat.
• Anodised aluminium boom equipped with two single line reefing system.
• Genoa furler.
• Continuous standing rigging in single strand stainless steel cable and chrome plated bronze turnbuckles including: forestay, double backstay, cap shrouds, inter and lower shrouds.
• Pre-stretched running rigging including: Main and Genoa halyards, boom topping lift, Main and Genoa sheets, two reefing lines, outhaul line, Mainsheet car control line, furling line, boom vang tackle.
• Mainsail equipped with two broad reef bands, with battens and bag. Furling Genoa with anti-UV protection.

Plumbing

• Polyethylene tanks have a total capacity of approximately 360 litres with inspection plates and electric gauges on tanks .
• Pressurised water system, 20 litre water heater.
• Electric bilge pump with strainer and controls on switchboard.
• Manual bilge pump operated from the cockpit.
• Bilge integrated in hull and keel with easy access to strainer under floor boards.
• Drainage of shower water by pumps direct to the sea, easily accessible under the washbasins.
