Custom M.A.T 12.20

The MAT 1220 is designed for a new generation of IRC racers for MAT, emphasising versatility both in performance profile and configurations. Because it is not an extreme typeform with a medium sized sail plan and reasonable displacement, stability and draft, it’s also optimized for ORC.

The premise for the boat is to produce a modern light design that is equally at home offshore as inshore.  The design combines features such as medium displacement, greater emphasis on bow overhang, fin keel of moderate draft, and a number of sail plan tweaks to arrive at a very competitive both inshore and offshore. The base rating for the fin keel version with the fin keel and a squaretop it could go up to 1.190.

The deck and styling with a large cockpit offer an optimal platform for high level racing as open space for fun family sailing. The interior can be completed to a range of fitouts from stripped racing to offshore racing to family racer/cruiser.  Working with engineer Steve Koopman of SDK Structures we have configured the boat to be as versatile as possible.

The boat has been modified to suit the ORC rule, with lot of hours spend to achieve the right handicap without losing speed in the water.

Special cradle for transportation on land. Cradle both for boat and keel. Seldén mast divisible for easier transportation

Measurements:

Length overall: 12.20m

Beam: 3,96m

Draught: 2,50m

Displacement: 5.250kg

Construction:

Hull, deck, bulkheads and all interior components in PVC foam cored composite glass sandwich. Vacuum assisted resin infusion. Laminated assembly of all components to hull and deck. Carbon fiber reinforced structural grid for keel and mast loads

Hull:

Hull color: White gelcoat

Bottom color: Nautix racing

Keel: Lead fin, fully CNC shaped lead fin keel cast around duplex stainless steel keel spar, draft 2.50m

Rudder and Steering: Isotop made prepreg carbon autoclave cured rudder and stock. Jefa self-aligning high performance rudder bearings. 900 mm Carbonautica GFC composite twin wheels

Motor:

Ocean volt SD15 motor 15 kW with Piccolo 5, 3.3 kW 220 V removable diesel power plant and a removable 40 L diesel tank.

Two blade folding Gori racing propeller

Tank capacities:

Water tank: 200L

Diesel tank: 40L

Holding tank: 40L

Deck:

8 x Seldén Performa 52 STP black winches for primaries, main sheet and backstay

Seldén mainsheet track 6:1 up down purchase and 2:1 mainsheet to winch

Seldén transverse jib tracks and ball bearing cars allowing up to 5 degrees sheeting angle

Seldén Black Magic ball bearing halyard lead blocks

Seldén Black Magic ball bearings primary blocks

Seldén composite control blocks

4 of Spinlock XX and 5 of XCS clutches

Custom alloy fairleads

Custom stainless-steel chainplates recessed in hull

Composite mast collar

SS stanchions, pulpit and pushpit with socketed to laminated bases

5 mm SS lifelines, Blue Wave terminals

Optional black composite stanchions and fluorescent synthetic lifelines

1 opening Lewmar foredeck hatch

2 opening Lewmar portlights

4 opening Lewmar flush hatches

Big Lewmar flush hatch in the back, size 70

Custom laminated tempered security glass coachroof windows

Recessed companionway sliding hatch

Electrics:

48 V system

20 kWh Lithium battery, 4 st x 5 kWh each

Batteries are movable - with 3 different mounting points - depending on rating system.

3 st 1.6 kW 220 V to 48 V chargers with separate stern connectors to charge from multiple sources.

Victron Cerbo display

48 V to 12 V Victron converter

12V 120 Ah Lithium battery

Piccolo 5 3.3 kW 220 V removable diesel power plant

Galvanic Isolator

Shore power

Victron Smart BatteryProtect 12/24V-220A

Victron LiFePO4 Battery 12,8V/200Aha – Smart - 2020

Victron VE.Bus BMS

Victron Cyrix-Li-ct 12/24V-230A combiner

Blue Smart IP22 Charger 12/20

IP300P/DSP BEP Fuse ANL 300A

1 x USB 12V outlets + 1 x 12v outlets

Almost all the electrical wiring has been renewed in 2022

Electronics:

BG 12" Nemesis mast display

BG H5000 Hercules processor

BG H5000 display

BG Precision 9 Compass

BG Depth, Speed and Wind sensor

BG V60B VHF and AIS

2 st Navstations with 27" 4k displays with wireless keyboard and trackball.

POE Ethernet system

Acksys AirWan17 industrial Wifi, Router and 4G modem

Nuvo5000 industrial Windows PC with Expedition

Galley:

Aluminium handrail

Storage under sink

Cabinet removable

Gas stove and furnace

Refrigerator

Hot water system 30 L removable

Enclosed heads:

Aluminium handrail

Shower

Waste tank with cover and deck suction connection.

Radiator

Cabinet removable

Oak door removable

Can Marine hand basin

Jabsco marine manual toilet

Sails:

North 3Di pinhead mainsail for transport

Albatross Jib M for transport

All sails from North Sails, 2023 in very good condition

Square Top Mainsail                                                         3Di RAW 870 16.800 Dpi

Jib l Light/Medium                                                            3Di RAW 870 12,600 Dpi

Jib2 Medium/Heavy                                                         3Di RAW 870 76,800 Dpi
 J3 Heavy                                                                                3Di RAW 87019,600 Dpi

Jib3.5 Heavy Weather OSR Max  NPL SportXi Aramid NL.Xil8Tv2
 A 1 Asymmetric                                                                                                   Airx 600 – 500 N

A 2 Asymmetric                                                                  Airx 600 – 500 N BAIN

A6 Asymmetric                                                                   Superkote SK 130

Code Zero (75% smg)                                                       3Di Downwind 706, 7,560 Dpi

Spinnaker Staysail                                                              NPL Code Xi Xi04 CD U

Mast and rigging:

Fractional sloop

Selden Carbon mast and boom.

Carbon mast, with carbon spreaders

Carbon boom - outhaul in boom with purchase system

Reef system with jammers included

Carbon rodkick with double windward sheeting

VHF antenna in mast top

Divisible mast for transportation

Alfalock halyard lock Main, Jib and Code 0

Halyards 2 jib, 1 fractional, 1 Code 0, 2 gennark, 1 main

Deck lightning - flood light

Mast Jack hydralic

Antal rail for rope and batcar system on mast

All Seldén deck gear - winches - blocks - winch handels

2 tacklines

Solution for spinnaker staysail

Solution for genua staysail

Jib cunningham for Helix North Sails

Jib barberhaul - double system - windward trimming

Liros Ropes - racing professional lines

Annual inspection and services done since new. Blue Ocean Oy Ab reserves the right to changes in this specification list. The boat and mast are stored in a boathouse when she is launched.
